Features:
-
The cover is elegent with fluent line and it is spraying with APS engineering plastic which has high-intensity, anticorrosion function and easy to clean. With key parts imported, it runs steadily without noise and comply with theory of ergonomics
-
20 sets of programme, broad screen touch LCD, with man-machine dialogue inerface, prompt identifying can be made in abnormal situation to make sure each operation can be indicated (online help)
-
The intelligent design gives the ability to deal with abnormal situation automatically. The synchronous animation show the present working process clearly
-
Environment-friendly inner circulated air cleaning system absorb, remove and decompose toxic and harmful gass in the instrument
-
Randomly setting start-up time and automatically showing finish time, make sure task is finished in stipulated time
-
10–60s adjustable time of dropping liquid, shaking basket, and drop liquid above cylinder once exchange cylinder to avoid liquid mix from one bath to another, in this way, service time of reagent can be prolonged, aviod dirty on the table
-
0-6 times/min adjustable stirring times (0 shows no-stirring), make sure all tissues immersed thorough, evenly and completed enough
-
Once power-off, protecting station No. 1-7 can be set, position of protecting station can be adjusted as required
|
Technical specification:
-
Numbers of stations: 12 (no.10, 11 and 12 are wax dispensing cylinder)
-
Volume of each station: 2 liter
-
Range of temperature: ambient-80 C
-
Temperature tolerance: +/-1 C
Processsing time of each station: anytime (No.1 station) 0-24 hrs (other stations)
-
Time of exchange station, delay, leachate:10-60s (adjustable), and leachate, basket shaking work above cylinder
-
Tissue protecting stations: No 1 – No 7 (adjustable)
-
Voltage: AC220V/50Hz, AC110V/60Hz
-
Power: 1000VA
-
Dimension: 1135x480x490 mm
-
Weight: 88kg
Features:
-
Self-control fan, it automatically starts up once basket goes up; as basket goes downwards, fan works 10s per min
-
Self-control illuminating lamp, it starts up in programming; touch any key to prolong to 2 min as the instrument is running
-
Waterless inner heating, high precision of controlling
-
Low energy-consuming control circuit, self-protection once power-off; display panel is still illumed and scrolling panel indicats it’s self-protecting situation as power-off, and time of running is more than 30 hrs
-
It can manually add the tissue during the auto running mode. Customer can check and add the tissue conveniently during operation process .
-
More than 150 tissues can be processed at a time
|
